Click Apply and then close the "Option Window."Īfter the paths have been verified or added, try typing CAP on the command line and press enter. If either location is missing the path, then use the "ADD" and "BROWSE" buttons on the right to navigate and select the path and then press OK.ħ. Verify that the installation folder for 2020 Cap is listed under “Trusted Location.” (Refer to reference image below)Ħ.
Verify that the installation folder for 2020 Cap is listed under “Support File Search Path.” ( Refer to reference Image Below)Ĥ. Click the Files tab and expand “Support File Search Path.”ģ. In AutoCAD type "OPTIONS" on the command line and press enter.Ģ. Follow the steps below to integrate 2020 Cap into AutoCAD:ġ. The default installation directory for 2020 Cap will be C:\Program Files (x86)\2020\CAP Studio. The current supported versions of Windows for 2020 Cap are Windows 10 and 11. The first step is to verify that the "Support File Search" path and "Trusted Location" path in the AutoCAD options has the installation folder for 2020 Cap listed. If 2020 Cap does not load, perform the manual integration described below. Open AutoCAD and Type CAP on the command line and press Enter.Ĩ. 2020 Cap should then load. Close the "Advanced Software" window and then close the "2020 Diagnostic" window.ħ. Click the button “ Integrate with AutoCAD”Ħ. Click the Advanced Maintenance… button in the lower right of the "Diagnostic" window.ĥ. From the 2020 Worksheet "Help" menu, choose Diagnostics.Ĥ. Once the software is loading properly for the user, admin rights can then be removed if necessary.ģ. You should follow these steps logged into the computer as the user who will be using the application and with full local admin rights. Note: 2020 Cap integration with AutoCAD is user profile specific. If it does not load or reports “unknown command,” then the following steps can be used to set it up for the first time. Normally you would type CAP on the command line within AutoCAD to load.
